Automate School Forms with Web Scraping in Ruby
My good friend and former colleague Yechiel recently wrote about automating Google Forms submissions in Ruby. He and I both share the same purpose for our automation, which is to save valuable time in the daily morning preparations of busy working families, but our schools use very different systems for their daily coronavirus health form requirements.
If you are interested in learning how to automate Google Forms submission then navigate over to Yechiel’s excellent post.
In this post I will share how I automated the submission process for our school system, which uses a custom website.
tl;dr You can find the code for this application on GitHub with instructions on how to use it.
For a successful submission of the daily school form my app needed to:
- Log in to the site with my username and password
- Check two HTML checkboxes
- Draw on an HTML5 Canvas element
- Press the “Submit” button
- Account for each child in my list and repeat each action for each child
- Skip a child in the list if their form had already been submitted
- Give me some feedback if the submission was successful or tell me if something went wrong
This is what the form looks like for each child:
To solve this problem I used Watir, which is a Ruby gem that lets your application interact with a web browser the way a person would interact with it. Watir enables you to click on links, fill out forms, submit them and more.
I added the three following gems to my
Gemfile, which is where you list your application dependencies:
gem 'dotenv' gem 'watir' gem 'webdrivers'
I used the
dotenv gem to help manage my environment variables in the application. Specifically, in order to not store my username and password in any public version control, I use environment variables for them and access the variables in the application.
webdrivers gem is used to make the Chrome Webdriver available, which simulates accessing a website in a Chrome browser.
Once I had my dependencies I was ready to build my app. I like to encapsulate my code in small methods that do as little as possible. It makes it easier for me to diagnose when things go wrong.
The first method I built was
#call, which serves as the entry point for the application. The method invokes the next method
#get_sign_in_page that instantiates the Watir instance and cicks on the first button that must be clicked on to get to the sign-in page:
def call(url) get_sign_in_page(url) end def get_sign_in_page(url) browser = Watir::Browser.new :chrome, headless: false browser.goto(url) click_first_sign_in(browser) end
The second method above then invokes
#click_first_sign_in, which does as it is called, namely clicking on that first sign in link:
def click_first_sign_in(page) page.link(:class => [ 'text-bold', 'color-white', 'edu-connect', 'btn', 'color-blue', 'border-blue', 'btn-connect-briut' ]).click fill_in_sign_in_form(page) end
I find the sign-in link using its collection of CSS classes and pass them to the instance method
#link of Watir as an Array of Strings. Once I identified the right button, then I click on it with the
#click method! Don’t you love when methods are named so well?
The method ends by invoking the next method,
#fill_in_sign_in_form, which completes the login process:
def fill_in_sign_in_form(page) page.text_field(id: /HIN_USERID/).set(ENV['USERNAME']) page.text_field(id: /Ecom_Password/).set(ENV['PASSWORD']) page.button(name: /loginButton2/).click fill_out_declaration(page) end
The method above finds the text fields in the form for the username and password and supplies my environment variables as their values. It then finds the submit button and clicks on it. Lastly, I then move on to the next method, which takes care of my kids health forms.
In the next method, I first get the list of kids by finding it in its
<div> using its CSS class. Then I iterate through the list of links in that
During the iteration, I check if the form each element (i.e. each child) has already been submitted. If it has then I output to the console a short message explaining that. If it has not, then I
#click on the kid and
def fill_out_declaration(page) kids_list = page.div(class: /name_student_infile/) kids_list.links.each do |kid| if check_already_submitted?(page) puts "Form already submited" next end kid.click complete_individual_form(page) end end
The individual form is processed for its requirements. That means that each of the two checkboxes are clicked and the application draws a bit on the Canvas element:
def complete_individual_form(page) # two checkboxes page.label(:xpath => '/html/body/div/section/div/div/form/div/div/b/div/div/label').click page.label(:xpath => '/html/body/div/section/div/div/form/div/div/b/div/p/label').click # canvas element canvas = page.browser.driver.find_element(:xpath => "/html/body/div/section/div/div/form/div/div/b/div/div/div/canvas") page.browser.driver.action.move_to(canvas, 50, 20).click_and_hold.move_to(canvas, 550, 85).release.perform page.browser.driver.action.move_to(canvas, 200, 85).click_and_hold.move_to(canvas, 75, 43).release.perform page.button(id: /btn_send/).click validate_success(page) end
After the form has been finished, I validate that it was performed successfully.
In the case of this specific website, all the error messages are already on the site but hidden behind a CSS class of
hidden. If there was an error then the
hidden class is removed and the error message becomes visible.
Similarly, if the
hidden class is removed on the success message, then it means the form was submitted successfully.
def validate_success(page) check_for_errors(page) if page.label(class: /answer_send color-red/).present? puts "Sent form successfully" end end def check_for_errors(page) if page.label(class: /fill_answer1 color-red/).present? puts "First checkbox not checked properly" end if page.label(class: /fill_answer2 color-red/).present? puts "Second checkbox not checked properly" end if page.label(class: /fill_sign color-red/).present? puts "Signature not recorded properly" end if page.label(class: /answer_send color-red hidden/).present? puts "Form not sent successfully" end end
At the very end, I needed to also include the method,
#check_already_submitted? that I referenced in the iteration of the list of children, but had not built yet:
def check_already_submitted?(page) page.link(:class => [ 'answer_send', 'pdf_wrap_create_briut', 'padding-right-lg-x', 'cursor-pointer' ]).present? end
Now, the file just needs an invocation to the entry point, which is as simple as adding
call(ENV['URL']) on a new line at the end.
Before the application is ready to be run we needed to make sure that there was a
.env file with the right variables, namely:
URL: The website entry point for the health form
USERNAME: Your username
PASSWORD: Your password
We also needed to add a few
require statements at the top of the file:
require 'dotenv' Dotenv.load! require 'webdrivers/chromedriver' require 'watir'
Now, from the command line we can run
bundle exec ruby declare.rb and watch the forms get filled out for us automatically!
If you don’t want to watch them, you can change
#get_sign_in_page and it will run in the background.
You can find the code for this application on GitHub.
